Product Name
Voltage
Compensation types
Controlling capacity
JKDSC
Q
1A
25
M:220V Q:380V
1A: simultaneously compensate 3F:individually compensate
25：25kvar 30：30kvar 40：40kvar
Adopts zero-crossing switching function, small inrush current(below 2 times), no rush to load and device.
No technical contact. No working noises. Operating stably and reliably.
Implementation standards
GB/T 29312
Working voltage
V
380V±15%(compensate simultaneously) 220V±15%(compensate individually)
Frequency
Hz
50
kvar
compensate simultaneously:25,30,40 compensate individually:30
Dielectric strength
Power frequency 2500
Weight
kg
＜ 3.4
