Default: complementation type 3: mixed compensation type
M:220V Q:380V
16:16 way
The ordering number for Model RPCF Intelligent Reactive Power Compensation Controller (mixed compensation type)of 220V voltage with 16 way and DC output voltage is RPCF3MD16.
The controller calculates the switching capacity with fundamental wave reactive power, to avoid any switching shocks and it displays the grid power factor correctly in the presence of harmonics.
High accuracy of power factor measurement, wide display range, 12 codes output option ways, high reliability when operating.
The max. value of output circuit is 16
Harmonics protection function
RPC is complementation type controller. RPCF3 is mixed compensation type(complementation simultaneously and complementation individually ) controller.
Industry Standard
JB/T 9663
Rated working voltage
AC 380V or ACx220V
Rated working current
AC 0-5A
Rated working frequency
45-65HZ
Sensitivity
50mA
Displayed power factor
0.001lead-0.001lag
Consumption
10VA
Protection grade
IP30
Project requirement
If users require other function, please note it when order.
